2304-3-00-01-00-00-07-0

Part Number: 2304-3-00-01-00-00-07-0<

Manufacturer: Mill-Max Manufacturing Corp.<

Description: TERM TURRET SINGLE L=2.64MM<

Data sheet: 2304-3-00-01-00-00-07-0

Specifications

Series	2304
RoHS	RoHS
Insulation	Non-Insulated
Part Status	Active
Termination	Swage
Mounting Type	Through Hole
Terminal Type	Single End
Contact Finish	Tin-Lead
Board Thickness	0.094" (2.39mm)
Flange Diameter	0.094" (2.39mm)
Staking Side ID	-
Staking Side OD	0.072" (1.83mm)
Contact Material	Brass Alloy
Length - Overall	0.217" (5.51mm)
Number of Turrets	Single
Length - Above Board	0.104" (2.64mm)
Length - Below Flange	0.113" (2.87mm)
Diameter - Turret Head	0.050" (1.27mm)
Mounting Hole Diameter	0.076" (1.93mm)
Contact Finish Thickness	200.0µin (5.08µm)
