2309-2-00-50-00-00-07-0

Part Number: 2309-2-00-50-00-00-07-0<

Manufacturer: Mill-Max Manufacturing Corp.<

Description: TERM TURRET PIN L=1.93MM<

Data sheet: 2309-2-00-50-00-00-07-0

Specifications

Series	2309
RoHS	RoHS
Insulation	Non-Insulated
Part Status	Active
Termination	Swage
Mounting Type	Through Hole
Terminal Type	Double End, Pin
Contact Finish	Tin-Lead
Board Thickness	0.062" (1.57mm)
Flange Diameter	0.078" (1.98mm)
Staking Side ID	-
Staking Side OD	-
Contact Material	Brass Alloy
Length - Overall	0.300" (7.62mm)
Number of Turrets	Single
Length - Above Board	0.076" (1.93mm)
Length - Below Flange	0.224" (5.69mm)
Diameter - Turret Head	0.045" (1.14mm)
Mounting Hole Diameter	0.064" (1.63mm)
Contact Finish Thickness	300.0µin (7.62µm)
