You are here:Home >> Product >> Connectors, Interconnects >> Terminals - Turret Connectors

3156-4-00-34-00-00-08-0

Part Number: 3156-4-00-34-00-00-08-0<

Manufacturer: Mill-Max Manufacturing Corp.<

Description: CIRCUIT PIN PRNTD .150" .082"<

Data sheet: 3156-4-00-34-00-00-08-0

Specifications

Series	3156
RoHS	RoHS
Insulation	Non-Insulated
Part Status	Active
Termination	Swage
Mounting Type	Through Hole
Terminal Type	Double End, Pin
Contact Finish	Gold
Board Thickness	0.125" (3.18mm)
Flange Diameter	0.093" (2.36mm)
Staking Side ID	-
Staking Side OD	-
Contact Material	Brass Alloy
Length - Overall	0.442" (11.23mm)
Number of Turrets	Single
Length - Above Board	0.150" (3.81mm)
Length - Below Flange	0.270" (6.86mm)
Diameter - Turret Head	0.050" (1.27mm)
Mounting Hole Diameter	0.076" (1.93mm)
Contact Finish Thickness	50.0µin (1.27µm)
