You are here:Home >> Product >> Connectors, Interconnects >> Terminals - Turret Connectors

2702-1-00-80-00-00-07-0

Part Number: 2702-1-00-80-00-00-07-0<

Manufacturer: Mill-Max Manufacturing Corp.<

Description: TERM TURRET SNG<

Data sheet: 2702-1-00-80-00-00-07-0

Specifications

Series	2702
RoHS	RoHS
Insulation	Non-Insulated
Part Status	Active
Termination	Swage
Mounting Type	Through Hole
Terminal Type	Single End
Contact Finish	Tin
Board Thickness	0.031" (0.79mm)
Flange Diameter	0.156" (3.96mm)
Staking Side ID	0.064" (1.63mm)
Staking Side OD	0.090" (2.29mm)
Contact Material	Brass Alloy
Length - Overall	0.356" (9.04mm)
Number of Turrets	Single
Length - Above Board	0.281" (7.14mm)
Length - Below Flange	0.075" (1.91mm)
Diameter - Turret Head	0.109" (2.77mm)
Mounting Hole Diameter	0.094" (2.39mm)
Contact Finish Thickness	200.0µin (5.08µm)
